호크케이블글랜드 라인업과 다운로드링크



안녕하세요 TIATIP 입니다.

Hawke(호크) 케이블글랜드 관련 자료를 다운로드할 수 있는 사이트링크를 요약해 드립니다.







Our Cable Glands cover the whole spectrum of armoured and non-armoured cable and applications from general industrial through increased safety, deluge, flameproof and explosion proof. The Cable Glands are available in Brass as standard with Stainless Steel and Aluminium, as an optional material on certain designs. The innovative design features included in the range make our Cable Glands the lowest lifetime cost solution.





Hazardous Area Cable Glands

Features

  • 501/414
  • 501/421
  • 501/423
  • 501/453/RAC
  • 501/453/RAC/L
  • 501/453/Universal
  • CSB 656N
  • ICG 623
  • ICG 653/Universal
  • ICG 653/Universal/L
  • PSG 553/RAC
  • SB 474
  •



    Group 1 Mining

    Features

  • 453/RAC
  • 453/T
  • 453/Universal
  • 623
  • 653/T
  • 653/Universal
  •





    North American Series Cable Glands

    Features

  • 153/X
  • 701
  • 710
  • 711
  • 713
  • 753
  • 755
  •



    Industrial Cable Glands

    Features

  • 114
  • 121 (Type A2)
  • 123 (Type A2)
  • 150/RAC (Type BW, BX and BZ)
  • 151/RAC (Type CW, CX and CZ)
  • 153/RAC (Type E1W, E1X and E1Z)
  • 153/RAC/L (Type E2W, E2X and E2Z)
  • 153/Universal (Type E1W, E1X and E1Z)
  •



    Increased Safety Cable Glands

    321























    국내 기술지원 및 상담구매처

    CUSTOMER SUCCESS IDK

    deric@jadongwha.com

    www.tiatip.com





    저작자 표시
    신고
    Posted by TIATIP

    댓글을 달아주세요:: 네티켓은 기본, 스팸은 사절

    Hawke PSG553RAC Cable Gland



    안녕하세요 TIATIP 입니다

    오늘 이 시간에는 Hawke 호크케이블그랜드 가운데 Hazardous Area Cable Gland Type인 PSG553RAC를 알아봅니다







    Cable Glands
    Hazardous Area
    Flameproof Exd & Increased Safety Exe
    Dual Certifi ed ATEX / IECEx

    Hawke PSG553RAC Cable Gland









    Hawke PSG 553/RAC Cable Gland







    Application

    • Outdoor or indoor use.
    • For use with single wire armour ‘W’, wire braid ‘X’ and steel tape armour ‘Z’ elastomer and plastic insulated cables.

    • For particular use with:-
    a) Cables that are not effectively filled, compact and/or circular, have tape bedding or have hygroscopic fillers.
    b) Cables that exhibit ‘cold flow’ characteristics.
    c) Enclosures for gas group IIC, under 2 litres in volume and containing an ignition source.
    d) Enclosures for gas groups IIA or IIB, which are greater than 2 litres in volume and contain an ignition source.





    Features

    • Provides a barrier seal to the individual insulated cores within the cable and prevents entry of the products of an explosion into the cable.
    • The required number of holes for the cores are punched in the seal by means of a special tool to suit the core size.
    • Provides armour clamping using one clamping arrangement for all armour/braid types.
    • Deluge protection option available contact Hawke Technical Sales for details.
    Provides a cable retention and low smoke and fume, zero halogen seal onto the cables outer sheath.





    Materials & Finishes

    • The PSG 553/RAC cable gland is manufactured in Brass (standard), Nickel Plated Brass, 316 Stainless Steel or Aluminium.
    • Brass NPT entries are nickel plated as standard.





    악세서리







    Technical Data

    • Flameproof Exd and Increased Safety Exe  II 2 GD ExtD A21.
    • Baseefa Certificate No. Baseefa06ATEX0056X.
    IECEx Certificate No. IECEx BAS 06.0013X.
    Suitable for use in Zone 1, Zone 2, Zone 21 and Zone 22.
    Suitable for use in Gas Groups IIA, IIB and IIC.
    Construction and Test Standards: IEC/EN 60079-0, IEC/EN 60079-1, IEC/EN 60079-7, IEC/EN 61241-0 and IEC/EN 61241-1.
    Ingress Protection: IP66, IP67 and IP 68 (30 metres for 7 days) to IEC/EN 60529 and NEMA 4X.
    Deluge protection to DTS01. (Deluge seal optional).
    Operating Temperature Range: -60°C to +80°C.
    Alternative certification options available:





    보다 자세한 사양(Technical Specification)은 다음의 세가지 첨부파일을 참고하시기 바랍니다.



    Hawke 호크 PSG553RAC 01.pdf

    Hawke 호크 Accessories 01.pdf

    Hawke 호크 PSG553RAC 조립도 01.pdf
