Chalmit 샬밋 458 EPDM Floodlight 기술사양



안녕하세요 TIATIP입니다. 오늘 이 시간에는 샬밋 일반조명제품군 가운데 Chalmit 458 EPDM Floodling 에 대해 살펴보도록 하겠습니다.





Chalmit Lighting

458 EPDM Floodlight

Industrial Application







The Chalmit 458 is high wattage, weatherproof, robust EPDM floodlight is versitile in its mounting suitability as this is available in a base-mounted version (/B) and pole-mounted option (/P). The range has excellent vibration resistance making it ideal for use in hostile marine environments.





The Chalmit 458 is manufactured from EPDM rubber with a heavy duty borosilicate front glass and wire guard for maximum protection. The Chalmit 458 is suitable for GLS and hps lamps with maximum continuous operating temperature of +30°C.

Models with GLS lamps can operate at an ambient temperature as low as -40°C. A universal control gear box is required for models with hps lamps.

Available in 150W HPS, 250W HPS and 300W GLS lamp options.







CAT REF.

458I/150/HS

458I/250/HS

458I/300/GL



Technical Data

458 Industrial.pdf



Notice : Specification are subject to change without notice.

주의사항 : 소개된 제품 시스템의 사양, 재질, 치수, 기타 기재 내용은 제조공급사의 사정이나, 성능향상을 위해 예고 없이 단종, 대체되거나 변경되는 경우가 있으므로 양해를 부탁 드립니다. 기타 문의 상담은 하기 전문대리점을 통해 진행해 주시기 바랍니다





국내 기술지원 및 구매상담

CUSTOMER SUCCESS IDK

CS CENTER 010.5353.9110

deric@jadongwha.com

www.tiatip.com



저작자 표시
신고
Posted by TIATIP

댓글을 달아주세요:: 네티켓은 기본, 스팸은 사절

Hawke 호크 ICG653Universal P/ICG653UNIV P타입 기술사양



안녕하세요 TIATIP 입니다.



이번 시간에는 호크(Hawke) 케이블글랜드 가운데 컴파운드(Compound)의 타입이자, 콜드플로우특성(cold flow characteristics)을 겸비한 ICG653Universal Series(ICG653Univ Series)의 신제품인 P타입을 살펴보겠습니다. 기존 호크(Hawke)의 ICG653UNIVERSAL(ICG653UNIV)에 비해 IP(Ingress Protection)등급의 테스트 기준특성이 보다 강화되어 있다는 특징이 있습니다.



호크 케이블글랜드

Hawke ICG653/Universal/P, Hawke ICG653/Univ/P

Cable Glands

Hazardous Area

Flameproof Exd & Increased Safety Exe & Restricted

Dual Certified ATEX/IECEx







호크의 대표적인 Universal(UNIV) 시리즈인 ICG653 UNIVERSAL과 501453 UNIVERSAL 타입입니다. 각 5번항목에서 확인할 수 있듯이  ICG653UNIV는 레드라벨이 501453 UNIV는 블랙라벨이 장착되어 있어 외관상으로 식별이 용이하도록 구성되어있습니다.



호크 케이블글랜드와 커넥터가 Hawke의 정크션박스(GRP JB/Stainless JB)와의 연결구성이 가능하다는 이미지 예시







호크 HAWKE ICG653UNIV 시리즈의 Brass 재질 및 구성이미지





호크 HAWKE ICG653UNIV 시리즈의 Nickel Plated Brass 재질 및 구성이미지





호크 HAWKE ICG653UNIV 시리즈의 개별 패키지 이미지







Hawke Application

• Outdoor or indoor use.

• For use with single wire armour ‘W’, wire braid ‘X’, steel tape armour ‘Z’, elastomer and plastic insulated cables.

• For particular use with:
- Cables that are not eff ectively fi lled, compact and/or circular, have tape bedding or have hygroscopic fi llers.
- Cables that exhibit ‘Cold Flow’ characteristics.
- Enclosures containing an ignition source in gas group IIC areas or containing an ignition source in a Zone 1 area.

• See technical section for installation rules and regulations.







호크 Hawke 케이블글랜드 장착예시





Hawke Technical Data

• Flameproof Exd and Increased Safety Exe II 2 GD Extb IIIC.

• Certifi cate No’s: Baseefa06ATEX0058X and IECEx BAS 06.0015X.

• Suitable for use in Zone 1, Zone 2, Zone 21, Zone 22 and in Gas Groups IIA,

  IIB and IIC.

• Construction and Test Standards:

   IEC/EN 60079-0, IEC/EN 60079-1, IEC/EN 60079-7 and IEC/EN 60079-31.





호크 HAWKE ICG653UNIVERSAL Series





• Ingress Protection:

  IP66, IP67, IP 68 : 60 metres for 6 hours to IEC/EN 60529.

• Deluge Protection to DTS01.

• Operating Temperature Range: -60°C to +80°C.

• Assembly Instruction Sheet: AI 461 & AI 462 IP68 Sealing Method.





호크

HAWKE





Features

• Provides a barrier seal to the individual insulated cores within the cable and prevents entry of the products of an explosion into the cable.

• Assembly of the cable gland compresses and distributes the compound evenly to create a barrier seal at the point of entry into the enclosure.

• The compound chamber may be separated from the cured compound to ensure that the chamber has been eff ectively fi lled. If required, external voids can be repaired.

• Provides armour clamping, using one clamping arrangement for all armour / braid types.

• Provides an outer deluge seal to prevent moisture ingress to the cable armour / braid.

• Provides a cable retention and low smoke and fume, zero halogen seal onto the cables outer sheath.

• Manufactured in Brass (standard), Nickel Plated Brass, 316 Stainless Steel or Aluminium.

• Brass NPT entries are nickel plated as standard.





호크

HAWKE





HAWKE Ordering Information

ICG653/UNIV/P/Os/M20, ICG653/UNIVERSAL/P/Os/M20

ICG653/UNIV/P/O/M20, ICG653/UNIVERSAL/P/O/M20

ICG653/UNIV/P/A/M20, ICG653/UNIVERSAL/P/A/M20

ICG653/UNIV/P/B/M25, ICG653/UNIVERSAL/P/B/M25

ICG653/UNIV/P/C/M32, ICG653/UNIVERSAL/P/C/M32

ICG653/UNIV/P/C2/M40, ICG653/UNIVERSAL/P/C2/M40

ICG653/UNIV/P/D/M50, ICG653/UNIVERSAL/P/D/M50

ICG653/UNIV/P/E/M63, ICG653/UNIVERSAL/P/E/M63

ICG653/UNIV/P/F/M75, ICG653/UNIVERSAL/P/F/M75

ICG653/UNIV/P/Os/1/2"NPT, ICG653/UNIVERSAL/P/Os/1/2"NPT

ICG653/UNIV/P/O/1/2"NPT, ICG653/UNIVERSAL/P/O/1/2"NPT

ICG653/UNIV/P/A/3/4"NPT, ICG653/UNIVERSAL/P/A/3/4"NPT

ICG653/UNIV/P/A/1/2"NPT, ICG653/UNIVERSAL/P/A/1/2"NPT

ICG653/UNIV/P/B/1"NPT, ICG653/UNIVERSAL/P/B/1"NPT

ICG653/UNIV/P/B/3/4"NPT, ICG653/UNIVERSAL/P/B/3/4"NPT

ICG653/UNIV/P/C/1-1/4"NPT, ICG653/UNIVERSAL/P/C/1-1/4"NPT

ICG653/UNIV/P/C/1"NPT, ICG653/UNIVERSAL/P/C/1"NPT

ICG653/UNIV/P/C2/1-1/2"NPT, ICG653/UNIVERSAL/P/C2/1-1/2"NPT

ICG653/UNIV/P/C2/1-1/4"NPT, ICG653/UNIVERSAL/P/C2/1-1/4"NPT

ICG653/UNIV/P/D/1-1/2"NPT, ICG653/UNIVERSAL/P/D/1-1/2"NPT

ICG653/UNIV/P/D/2"NPT, ICG653/UNIVERSAL/P/D/2"NPT

ICG653/UNIV/P/E/2"NPT, ICG653/UNIVERSAL/P/E/2"NPT

ICG653/UNIV/P/E/2-1/2"NPT, ICG653/UNIVERSAL/P/E/2-1/2"NPT

ICG653/UNIV/P/F/2-1/2"NPT, ICG653/UNIVERSAL/P/F/2-1/2"NPT

ICG653/UNIV/P/F/3"NPT, ICG653/UNIVERSAL/P/F/3"NPT











Hawke Accessories









호크 Hawke ICG653 Universal Series 설치동영상









ICG653 UNIV P Spec(UPD111213).pdf

ICG653 UNIV Spec.pdf

ICG653 UNIV P (Issue B 12-13) - RELEASED 11Dec13.pdf

ICG653 UNIV P Glands IP68 (Issue C 12-13) - RELEASED 11Dec13.pdf

2.Hawke Accessories 2013 IDK.pdf
