Baumer 바우머 마그네틱 앵글센서 MDRM 18U9501 사양소개



안녕하세요 TIATIP 에디터입니다. 절기상 대설이후 눈이 내리고 또 추운 겨울입니다. 여러분 모두 따뜻하고 훈훈한 겨울나시길 바랍니다.



오늘 이 시간에는 바우머 마그네틱 앵글센서가운데 MDRM 18U9501 사양에 대해 관련자료를 올리고 간단한 원리를 설명하는 내용을 포스팅해보았습니다.



Baumer

Magnetic Angle Sensors

MDRM Series, MDRM 18U9501









Magnetic sensors are proven in the field and are constantly further developed and refined. Thanks to their substantial benefits like high detection speed or extreme dirt resistance and by utilizing a non-contact and wear free sensing principle they are indispensable in many applications. The extensive Baumer portfolio provides magnetic sensors with different techniques and designs and hence the optimal solution for every application.





General information



A magnetic angular sensor identifies the rotation angle of a permanent magnet in respect to the sensor. The integrated electronics will evaluate the value into an analog electric output signal.





Fuctional principle



The heart of a magnetic angular sensor is the integrated dual differential Hall element which builds an electrical parameter related to the flux direction of an exterior magnetic field. This magnetic field rotating
about the element’s center axis generates two sinusoids shifted by 90° which are utilized to detect the rotation angle for output as an absolute value. The integrated electronics evaluates the sinusoids into a linear voltage or current signal. The absolute dection principle ensures output
of the correct rotation angle even after power failure.





Permanent magnet



When attaching the magnet make sure that its magnetization direction (north / south pole) is aligned in a parallel manner to the sensor’s sensing face. The carrier material to hold the magnet should be non-ferromagnetic
(e.g. no steel), otherwise it will hamper the sensing distance.







Working distnace

The magnet rotor or the permanent magnet must be attached within the specified working distance to the sensor. Observe the specifications in the data sheet for axial displacement.







Zero signal

For coarse zero signal tuning, align the keyways provided at sensor and magnet rotor (accessory) with each other. Finetuning will be performed electronically by the downstream control. Clockwise rotation of the permanent magnet will generate a rise in the output signal.





Mounting

The sensor must be mounted in the specified orientation. Coarse zero point adjustment by keyway, fine electronically. Increasing output signal when rotating clockwise.







Technical Data

Baumer, 바우머, Magnetic Sensor, 마그네틱센서, Magnetic Angle Sensor, 마그네틱앵글센서, MDRM, MDRM18U9501, 11084376, 11052887, 11052885, 11016706, 11087165, 10151658, ZADAP

0.Magnetic Sensors Master CAT 201201XX.pdf

MDRM_18U9501 Datasheet IDK EN.pdf

MDRM_18U9501 Manual IDK EN.pdf

MDRM_18U9501 Informationt IDK EN.pdf

Note : Specifications are subject to change without notice.

소개된 제품 시스템의 사양, 재질, 치수, 기타 기재 내용은 제조공급사의 사정이나, 성능향상을 위해 예고 없이 단종, 대체되거나 변경되는 경우가 있으므로 양해를 부탁 드립니다. 기타 문의 상담은 하기 전문점을 통해 진행해 주시기 바랍니다.
